| Hero Xtreme 160R 4V Standard General Features | |
|---|---|
| Engine Type | 4 Stroke, Air-Oil Cooled, 4 Valve |
| Top Speed | - |
| Engine Capacity | - |
| Starting | - |
| Brakes | Double Disc |
| Gear Box | 5 Speed |
| Fuel Tank Capacity | 12 L |
| Tyre Type | Tubeless |
| Hero Xtreme 160R 4V Standard Standard Features | |
|---|---|
| Brakes | Double Disc |
| Pass Switch | |
| Cooling System | - |
| ABS | Dual Channel |
| CBS | - |
| Ebs | - |
| Body Graphics | - |
| Carry Hook | - |
| Shutter Lock | - |
| Hero Xtreme 160R 4V StandardEngine & performance | |
|---|---|
| Engine Type | 4 Stroke, Air-Oil Cooled, 4 Valve |
| Displacement | 163.2 |
| Mileage | - |
| Bore | 66.5 mm |
| Stroke | 47.0 mm |
| Compression Ratio | 10.1:1 |
| Maximum Power | 16.9 PS @ 8500 rpm |
| Maximum Torque | 14.6 Nm @ 6500 rpm |
| Starting | Self Start Only |
| Maximum Speed | - |
| Hero Xtreme 160R 4V StandardTransmission | |
|---|---|
| Gear Box | 5 Speed |
| Clutch | Multiplate Wet |
| Transmission Type | Manual |
| Hero Xtreme 160R 4V Standard Fuel | |
|---|---|
| Fuel Capacity | 12 L |
| Supply System | - |
| Fuel Reserve | - |
| Fuel Gauge | Digital |
| Digital Fuel Gauge | - |
| Hero Xtreme 160R 4V StandardBrake | |
|---|---|
| Brakes | Double Disc |
| Front Brake | Disc |
| Rear Brake | Disc |
| Hero Xtreme 160R 4V StandardTyre Size | |
|---|---|
| Tyre Size | Front :-100/80-17 Rear :- 130/70-17 |
| Radial Tyres | Yes |
| Hero Xtreme 160R 4V StandardWheel Size | |
|---|---|
| Wheel Size | Front :-431.8 mm, Rear :-431.8 mm |
| Wheel Base | 1333 mm |
| Hero Xtreme 160R 4V StandardChassis and Suspension | |
|---|---|
| Bike Suspension | - |
| Hero Xtreme 160R 4V StandardFrame | |
|---|---|
| Chassis/ Frame | - |
| Hero Xtreme 160R 4V StandardElectrical | |
|---|---|
| Ignition | - |
| Battery Type | - |
| Head Lamp | - |
| Tail Lamp | - |
| Turn Signal Lamp | LED |
| Hero Xtreme 160R 4V Standard Exterior Dimensions | |
|---|---|
| Length | 2029 mm |
| Height | 1052 mm |
| Width | 793 mm |
| Ground Clearance | 165 mm |
| Saddle Height | 795 mm |
| Kerb Weight | 146 kg |
| Total Weight | - |
| Weight Carrying Capacity | - |
| Chassis/ Frame | - |
| Wheel Base | 1333 mm |
